Step 1
Measure the Width (1) and Height (2) of your door opening in feet and inches.
The rough opening should be the same size as the door.
Step 2
Measure the area labelled Left Side (3) and Right Side (4). For the installation of a standard torsion spring system, a minimum of 3-3/4” is required on each side of the vertical track.
Step 3
Measure the area labelled Headroom (5).
This is the distance between the top of the door opening and the ceiling. 12" is necessary for a standard torsion spring system.
If the headroom is restricted, specialized hardware is available. We require additional headroom for the installation of an automatic garage door opener.
Please Note: If the garage door height extends above the opening, the headroom measurement should be adjusted proportionately.
Step 4
Measure the area labelled Backroom (6).This is the distance from the garage door opening to the back wall of the garage. Door height must be 18" or more.
Please Note: Additional backroom may be necessary for the installation of an automatic garage door opener.
Step 5
Send Canadoor your garage door measurements for your no-obligation quote. A member of our team will be in touch within one business day.
